NG(H) Песчаный насос

Насосы типа NG(Н) – одноступенчатые, одностороннего всасывания, консольные, горизонтальные, центробежные шламовые насосы. Они предназначены для непрерывной перекачки самых сложных высокоабразивных шламов, которые содержат слишком большие твердые частицы, чтобы их можно было перекачивать обычными насосами. Они подходят для доставки шламов в горнодобывающей промышленности, взрывоопасных шламов при плавке металлов, дноуглубительных работ в земснарядах и руслах рек, а также в других областях. Эта серия насосов особенно подходит для условий работы с высоким расходом, высокой концентрацией и высоким напором, хорошими характеристиками NPSH и высокой стойкостью к истиранию, может широко использоваться при транспортировке высокотемпературных и сильноабразивных шламов.

key word:

froth pump、gravel pump

Category:

горизонтальный глинистый насос

Песчано-гравийный и земснарядный насос

sales@naimo-pump.com

Feedback

NG(H) Песчаный насос

TOP

Таблица выбора

Размер формы

Состав

Параметры материала

Code	Material #	Hardness HRC	Performance	Application
A01	KmTBCr8	≥55	Abrasion-resistant performance is about 10% less than A05	Mud & slag application
A03	KmTBNi4Cr2	≥56	Abrasion-resistant performance is about 20% less than A05	Neutral water-sand slurry and applications with lower impact load
A05	KmTBCr26	≥56	Ranks second only to A07 in abrasion-resistant performance; fair corrosion-resistant performance.	High impact load abrasion condition; PH rate ranging from 5 to 12
A07	KmTBCr15Mo3	≥59	Best abrasion-resistant performance; corrosion-resistant performance is inferior to A05	High impact load abrasion condition
A11	KmTBCrMnMo3	38-42	Mild corrosion-resistant; lower hardness; drilling and tapping operations are applicable.	Fine particles with light abrasion.
A33		≥35	Abrasion-resistant performance is close to A03; fair corrosion-resistant performance	Oxide slurry with PH rate no less than 1, like phosphor-gypsum in phosphate fertilizer plant, nitric acid, sulph-oacid and phosphoric acid, etc.
A49		≥43	Fair abrasion-resistant performance, close to A03; fair corrosion-resistant performance in media with lower PH rate.	Corrosion conditions with low PH rate, especially for flue gas and FGD devices for media of PH≥4; general suitable for lower acid condition.
A12		≥62	Higher abrasion-resistant performance than A05; fair corrosion-resistant performance; suitable for media with PH rate is 6-16, where A05 is not suitable.	High abrasive slurry with fine particles.
A61		63-68	Optimized abrasion-resistant performance than A12	High abrasive slurry with fine particles.

Material	Material #	Applications
Natural Rubber	R08	R08 is low to medium hardness rubber used for impellers where slurry contains fine particles and erosive.
Natural Rubber(soft)	R26	R26 is soft natural rubber used for liners where slurry contains fine particle and more erosive.
Natural Rubber(soft)	R33	R33 is widely used for frame plate liners, cover plate liners and impellers. Maximal particle diameter is 10mm; impeller peripheral speed should be less than 25m/s; suitable for temperature not exceeding 75℃.
Natural Rubber	R55	R55 is widely used for impellers, frame plate liners, cover plate liners and throat bushes. Maximal particle diameter can be 20mm, impeller peripheral speed should be less than 27.5m/s; suitable for temperature not exceeding 75℃.
EPDM Rubber	S01	S01 is widely used for impellers, frame plate liners, cover plate liners and throat bushes. Maximal particle diameter can be 8mm; impeller peripheral speed should be less than 25m/s; suitable for temperature not exceeding 120℃(continuous duty) or 140℃(discontinuous duty).
Nitrile Rubber(NBR)	S12	S12 is widely used for frame plate liners, cover plate liners, throat bushes, lip seals, impellers and expellers. Maximal particle diameter is 7mm; impeller peripheral speed should be less than 27m/s; suitable for temperature not exceeding 95℃.
Butyl Rubber	S21	S21 is widely used for impellers, frame plate liners, cover plate liners, expellers, volute seals and throat bushes,. Maximal particle diameter can be 7mm; impeller peripheral speed should be less than 30m/s; suitable for temperature not exceeding 100℃.
Hypalon	S31	S31 can be used for impellers, frame plate liners, cover plate liners and throat bushes,. It is recommended to use for strong acid slurry with mild or moderate corrosion. Maximal particle diameter can be 10mm; impeller peripheral speed should be less than 30m/s; suitable for temperature not exceeding 110℃.

Consult NAIMO Pump Industry for unlisted materials.
